The SXT LTE is a special variant of our popular SXT device, and doesn’t include a 802.11 wireless device. Instead, it has a built in high quality LTE Category 3 modem for speeds of up to 100Mbit/s downlink and 50 Mbit/s uplink.
A perfect device for remote locations that are within cellular network coverage. Due to it’s professional LTE chip and high gain antenna, it can provide connectivity for your building even where cell phones can’t.
The signal LEDs show LTE signal level for easy positioning. The SXT LTE supports the popular LTE FDD bands 3 (1800MHz) and 7 (2600MHz), has a standard SIM slot and is not backwards compatible with older networks.
Included: 24v Power Supply, Metal ring, PoE Injector
| Details | |
|---|---|
| Product code | RBSXTLTE3-7 |
| CPU nominal frequency | 400 MHz |
| CPU core count | 1 |
| Size of RAM | 64 MB |
| 10/100 Ethernet ports | 1 |
| Supported input voltage | 11 V - 57 V |
| PoE in | Yes |
| Voltage Monitor | Yes |
| PCB temperature monitor | Yes |
| Dimensions | 140x140x105mm |
| Operating System | RouterOS |
| Operating temperature range | -30 + 70 C |
| License level | 3 |
| Antenna gain DBI | 9 |
| CPU | AR7241 |
| Max Power consumption | 5W |
| Number of chains | 2 |
| Storage type | NAND |
| Storage size | 128 MB |
| RBSXTLTE3-7 | AR7241 100M 1 port test | ||||||
| Mode | Configuration | 1518 byte | 512 byte | 64 byte | |||
| kpps | Mbps | kpps | Mbps | kpps | Mbps | ||
| Bridging | none (fast path) | 8.1 | 98.6 | 23.5 | 96.3 | 148.0 | 75.8 |
| Bridging | 25 bridge filter rules | 8.1 | 98.6 | 23.5 | 96.3 | 53.7 | 27.5 |
| Routing | none (fast path) | 8.1 | 98.6 | 23.5 | 96.3 | 148.0 | 75.8 |
| Routing | 25 simple queues | 8.1 | 98.6 | 23.5 | 96.3 | 92.8 | 47.5 |
| Routing | 25 ip filter rules | 8.1 | 98.6 | 23.5 | 96.3 | 37.5 | 19.2 |
Part Number:
RBSXTLTE3-7
Προμηθευτές:
MikroTik
LAN 10/100 ports:
Lan 10/100 Ports: 1
Gigabit Ports:
Gigabit Ports: none
SFP 1G Ports:
SFP 1G Ports: none
SFP 10G Ports:
SFP 10G Ports:none
MiniPCI:
mPCI: none
Antenna Chains:
Antenna Chains: 2
CPU:
CPU: AR7241
Wireless Chip Model:
Wireless Chip Model: GDM7240CB20BGT
Architecture:
Architecture: MIPS-BE
Licence Level:
Licence: Level3
USB:
- USB: No
Memory cards:
- Memory Cards: No
Integrated Wireless:
- Integrated Wireless: No
Voltage Monitor:
- Voltage Monitor: Yes
Temperature sensor:
- Temperature sensor: Yes
Serial Port:
- Serial Port: No
PoE out:
- PoE out: No
Wireless standards:
- Wireless standards: none
