The World’s Smartest 802.11g Access Point with Adaptive Wi-Fi Signaling, Reliable Meshing and Automatic Interference Avoidance
ZoneFlex 2942 offers features and functions not available in any low-end consumer access point (AP) or high-end wireless LAN (WLAN) system. Yet, surprisingly, it’s the industry’s most cost-effective 802.11g wireless solution. Go figure! It supports Smart Mesh Networking, to streamline complex deployment headaches and eliminate running Ethernet cabling to every access point. This cuts down on operational overhead, making it ideal for hotels, schools, airports, and enterprises everywhere.
Self-Adjusting, High-Performance BeamFlex Smart Antenna Technology.
- Automatically adapts to constant changes in the environment
- Steers Wi-Fi signals to the best route
- Enables high performance, extended coverage, and multimedia support
Easy to Configure and Deploy.
- Can be used by non-IT person to create a sophisticated, plug-and-play, multimedia WLAN in minutes
- No RF tuning or client configuration required
- Web-based wizard enables easy configuration through ZoneDirector
Perfect for Hotzone Operators.
- Ideal for delivering business-class hot zone services, such as voice over Wi-Fi, IP-based video, or secure enterprise access
- Dual-polarized directional antenna system provides stable connectivity to any Wi-Fi-enabled handheld device,
- Flicker-free support for concurrent video streams and voice over Wi-Fi calls
ZoneFlex Architecture
Dynamic RF Management
| Physical Characteristics | |
|---|---|
| Power |
|
| Physical Size | 19.43cm (L), 14.43cm (W), 10.16cm (H) |
| Weight | 680 grams (1.50 lbs) |
| Antenna |
|
| Ethernet ports |
|
| LED display | Power/status, Ethernet status, wireless status, wireless network quality indicator, Director status |
| Lock Option | Integrated Kensington lock |
| Environmental conditions |
|
| Performance and Supported Configurations | |
| Concurrent stations | Up to 100 |
| Target UDP throughput | 15-20 Mbps (54 Mbps bursts) sustainable throughout a 5000 square foot (460 sq meter) public area |
| Simultaneous Vo-Fi clients | up to 20 |
| Traffic Management and Quality of Services | |
| Classes of service | Voice, video, best effort and background |
| Software queues | Four per station |
| 802.11e | Supported |
| Automatic traffic classification | Automatic type of service tagging for multicast video packets |
| Rate Limiting | Supported |
| VLAN support | 802.1Q |
| Heuristic classification | Supported |
| Deployment | |
| Options |
|
| Management | |
| Configuration | Web user interface, CLI (Telnet), SSH HTTP/S, SNMP statistics interface. TR-069 through FlexMaster |
| Statistics | LAN, wireless and associated stations (accessible via Web UI) |
| Auto AP Software updates | FTP or TFTP, remote auto available |
| Wi-Fi | |
| Standards | 802.11b/g |
| Supported data rates | 54, 48, 36, 24, 18, 12, 11, 5.5, 2, 1 Mbps |
| Channels |
|
| Auto channel selection | Supported |
| RF power output |
|
| Transmit power control | Supported |
| BSSID | up to eight |
| Power Save | Supported |
| Wireless Security |
|
| Certifications |
|
Part Number:
ZoneFlex 2942
Προμηθευτές:
Ruckus Wireless
